Cayman
AMD Radeon 6970
Specifiche:* Up to 880MHz Engine Clock
* 2GB GDDR5 Memory
* 1375MHz Memory Clock (5.5 Gbps GDDR5)
* 176 GB/s memory bandwidth (maximum)
* 2.7 TFLOPs Single Precision compute power
* 683 GFLOPs Double Precision compute power
* TeraScale 3 Unified Processing Architecture
o 1536 Stream Processors
o 96 Texture Units
o 128 Z/Stencil ROP Units
o 32 Color ROP Units
o Dual geometry and dual rendering engines
* High Speed 256-bit GDDR5 memory interface
* PCI Express 2.1 x16 bus interface
* “Eye-Definition” graphics
o New and advanced architecture
+ Full DirectX® 11 support
+ Scalable geometry processing technology
+ Shader Model 5.0
+ DirectCompute 11
+ Dual advanced programmable hardware tessellation units
+ Accelerated multi-threading
+ HDR texture compression
+ Order-independent transparency
o OpenGL 4.1 support
o Image quality enhancement technology
+ Up to 24x multi-sample and super-sample anti-aliasing modes
+ Adaptive anti-aliasing
+ Enhanced Quality Anti-Aliasing (EQAA)
+ Morphological Anti-Aliasing (MLAA)
+ 16x angle independent anisotropic texture filtering
+ 128-bit floating point HDR rendering
* AMD Eyefinity multi-display technology1
o Native support for up to 4 simultaneous displays
+ Up to 6 displays supported with DisplayPort 1.2 Multi-Stream Transport
o Independent resolutions, refresh rates, color controls, and video overlays
o Display grouping
+ Combine multiple displays to behave like a single large display
* AMD EyeSpeed visual acceleration2
o AMD Accelerated Parallel Processing (APP) technology3,4
+ OpenCL 1.1 Support
+ DirectCompute 11
+ Double Precision Floating Point
+ Accelerated video encoding, transcoding, and upscaling
o UVD 3 dedicated video playback accelerator
+ MPEG-4 AVC/H.264
+ VC-1
+ MPEG-2 (SD & HD)
+ Multi-View Codec (MVC)
+ MPEG-4 part 2 (DivX, Xvid)
+ Adobe Flash
o Enhanced Video Quality features
+ Advanced post-processing and scaling
+ Dynamic contrast enhancement and color correction
+ Brighter whites processing (Blue Stretch)
+ Independent video gamma control
+ Dynamic video range control
o Dual-stream HD (1080p) playback support
o DXVA 1.0 & 2.0 support
* AMD HD3D technology5
o Stereoscopic 3D display/glasses support
o Blu-ray 3D support
o Stereoscopic 3D gaming
o 3rd party Stereoscopic 3D middleware software support
* AMD CrossFireX™ multi-GPU technology6
o Dual, triple or quad-GPU scaling
* Cutting-edge integrated display support
o DisplayPort 1.2
+ Max resolution: 2560x1600 per display
+ Multi-Stream Transport
+ 21.6 Gbps bandwidth
+ High bit-rate audio
o HDMI 1.4a with Stereoscopic 3D Frame Packing Format, Deep Color, xvYCC wide gamut support, and high bit-rate audio
+ Max resolution: 1920x1200
o Dual-link DVI with HDCP
+ Max resolution: 2560x1600
o VGA
+ Max resolution: 2048x1536
* Integrated HD audio controller
o Output protected high bit rate 7.1 channel surround sound over HDMI with no additional cables required
o Supports AC-3, AAC, Dolby TrueHD and DTS Master Audio formats
* AMD PowerPlay™ power management technology3
o AMD PowerTune technology
+ Intelligent power management hardware
o Dynamic power management with low power idle state
o Ultra-low power state support for multi-GPU configurations
* AMD Catalyst™ graphics and HD video configuration software
o Software support for Windows 7, Windows Vista, and Windows XP
o AMD Catalyst™ Control Center - AMD Catalyst™ software application and user interface for setup, configuration, and accessing features of AMD Radeon products.
o Unified Graphics display driver - AMD Catalyst™ software enabling other PC programs and devices to use advanced graphics, video, and features of AMD Radeon™ products.
Recensioni
TechSpot: 6970 http://www.techspot.com/review/348-amd-radeon-6970/" onclick="window.open(this.href);return false;
PureOverclock: http://www.pureoverclock.com/article1164.html" onclick="window.open(this.href);return false;
TomsHardware: http://www.tomshardware.com/reviews/...yman,2818.html" onclick="window.open(this.href);return false;
TweakTown: 6970 http://www.tweaktown.com/reviews/373...ard/index.html" onclick="window.open(this.href);return false;
Hexus: http://www.hexus.net/content/item.php?item=27983" onclick="window.open(this.href);return false;
HardwareZone: http://www.hardwarezone.com/features/view/109424" onclick="window.open(this.href);return false;
HardwareHeaven: http://www.hardwareheaven.com/review...roduction.html" onclick="window.open(this.href);return false;
HardwareCanucks: http://www.hardwarecanucks.com/forum...50-review.html" onclick="window.open(this.href);return false;
Bit-Tech: 6970 http://www.bit-tech.net/hardware/gra...-6970-review/1" onclick="window.open(this.href);return false;
Lab501: http://lab501.ro/placi-video/gigabyt...970-si-hd-6950" onclick="window.open(this.href);return false;
Anandtech: http://www.anandtech.com/show/4061/amds" onclick="window.open(this.href);return false; ... on-hd-6950
HotHardware: http://hothardware.com/Reviews/AMD-R...-Enter-Cayman/" onclick="window.open(this.href);return false;
Guru3d: http://www.guru3d.com/article/radeon-6950-6970-review/" onclick="window.open(this.href);return false;
Legion Hardware: 6970 http://www.legionhardware.com/articl...970_2gb,1.html" onclick="window.open(this.href);return false;
PcPer: http://www.pcper.com/article.php?aid=1051" onclick="window.open(this.href);return false;
FudZilla: http://www.fudzilla.com/reviews/item...hd-6950-tested" onclick="window.open(this.href);return false;
TechPowerUp: 6970 - hhttp://www.techpowerup.com/reviews/HIS/Radeon_HD_6970/" onclick="window.open(this.href);return false;
VR-Zone: http://vr-zone.com/articles/amd-rade...html?doc=10474" onclick="window.open(this.href);return false;
HardOCP: http://www.hardocp.com/article/2010/...eo_card_review" onclick="window.open(this.href);return false;
Benchmark Reviews: 6970 http://benchmarkreviews.com/index.ph...=606&Itemid=72" onclick="window.open(this.href);return false;
Benchmark Reviews(PowerColor): 6970 http://benchmarkreviews.com/index.ph...=605&Itemid=72" onclick="window.open(this.href);return false;
computerbase: http://www.computerbase.de/artikel/graf" onclick="window.open(this.href);return false; ... einleitung
Dimensioni della 6970-5870
Il pcb:
AMD Radeon 6950
Specifiche
AMD Radeon™ HD 6950 GPU Feature Summary
* Up to 800MHz Engine Clock
* 2GB GDDR5 Memory
* 1250MHz Memory Clock (5.0 Gbps GDDR5)
* 160 GB/s memory bandwidth (maximum)
* 2.25 TFLOPs Single Precision compute power
* 562.5 GFLOPs Double Precision compute power
* Double slot form factor
* TeraScale 3 Unified Processing Architecture
o 1408 Stream Processors
o 88 Texture Units
o 128 Z/Stencil ROP Units
o 32 Color ROP Units
* High Speed 256-bit GDDR5 memory interface
* PCI Express 2.1 x16 bus interface
* “Eye-Definition” graphics
o New and advanced architecture
+ Full DirectX® 11 support
+ Scalable geometry processing technology
+ Shader Model 5.0
+ DirectCompute 11
+ Dual advanced programmable hardware tessellation units
+ Accelerated multi-threading
+ HDR texture compression
+ Order-independent transparency
o OpenGL 4.1 support
o Image quality enhancement technology
+ Up to 24x multi-sample and super-sample anti-aliasing modes
+ Adaptive anti-aliasing
+ Enhanced Quality Anti-Aliasing (EQAA)
+ Morphological Anti-Aliasing (MLAA)
+ 16x angle independent anisotropic texture filtering
+ 128-bit floating point HDR rendering
* AMD Eyefinity multi-display technology1
o Native support for up to 4 simultaneous displays
+ Up to 6 displays supported with DisplayPort 1.2 Multi-Stream Transport
o Independent resolutions, refresh rates, color controls, and video overlays
o Display grouping
+ Combine multiple displays to behave like a single large display
* AMD EyeSpeed visual acceleration2
o AMD Accelerated Parallel Processing (APP) technology3,4
+ OpenCL 1.1 Support
+ DirectCompute 11
+ Double Precision Floating Point
+ Accelerated video encoding, transcoding, and upscaling
o UVD 3 dedicated video playback accelerator
+ MPEG-4 AVC/H.264
+ VC-1
+ MPEG-2 (SD & HD)
+ Multi-View Codec (MVC)
+ MPEG-4 part 2 (DivX, Xvid)
+ Adobe Flash
o Enhanced Video Quality features
+ Advanced post-processing and scaling
+ Dynamic contrast enhancement and color correction
+ Brighter whites processing (Blue Stretch)
+ Independent video gamma control
+ Dynamic video range control
o Dual-stream HD (1080p) playback support
o DXVA 1.0 & 2.0 support
* AMD HD3D technology5
o Stereoscopic 3D display/glasses support
o Blu-ray 3D support
o Stereoscopic 3D gaming
o 3rd party Stereoscopic 3D middleware software support
* AMD CrossFireX™ multi-GPU technology6
o Dual, triple or quad-GPU scaling
* Cutting-edge integrated display support
o DisplayPort 1.2
+ Max resolution: 2560x1600 per display
+ Multi-Stream Transport
+ 21.6 Gbps bandwidth
+ High bit-rate audio
o HDMI 1.4a with Stereoscopic 3D Frame Packing Format, Deep Color, xvYCC wide gamut support, and high bit-rate audio
+ Max resolution: 1920x1200
o Dual-link DVI with HDCP
+ Max resolution: 2560x1600
o VGA
+ Max resolution: 2048x1536
* Integrated HD audio controller
o Output protected high bit rate 7.1 channel surround sound over HDMI with no additional cables required
o Supports AC-3, AAC, Dolby TrueHD and DTS Master Audio formats
* AMD PowerPlay™ power management technology3
o AMD PowerTune technology
+ Intelligent power management hardware
o Dynamic power management with low power idle state
o Ultra-low power state support for multi-GPU configurations
* AMD Catalyst™ graphics and HD video configuration software
o Software support for Windows 7, Windows Vista, and Windows XP
o AMD Catalyst™ Control Center - AMD Catalyst™ software application and user interface for setup, configuration, and accessing features of AMD Radeon products.
o Unified Graphics display driver - AMD Catalyst™ software enabling other PC programs and devices to use advanced graphics, video, and features of AMD Radeon™ products.
Foto:
Rcensioni:
TechPowerUp: 6950 - http://www.techpowerup.com/reviews/HIS/Radeon_HD_6950/" onclick="window.open(this.href);return false;
TechPowerUp: 6950 CF http://www.techpowerup.com/reviews/A...950_CrossFire/" onclick="window.open(this.href);return false;
Vortez: 6950 http://www.vortez.co.uk/articles_pag...gb_review.html" onclick="window.open(this.href);return false;
TweakTown: 6950 http://www.tweaktown.com/reviews/373...ard/index.html" onclick="window.open(this.href);return false;
Eteknix: 6950 http://www.eteknix.com/graphics/his-...rd-review-471/" onclick="window.open(this.href);return false;
Modders: 6950 http://www.modders-inc.com/modules.p...Story&reid=340" onclick="window.open(this.href);return false;
HiTechLegion: 6950 http://hitechlegion.com/reviews/vide...hd-6950-review" onclick="window.open(this.href);return false;
PcWorld: 6950 http://www.pcworld.com/reviews/produ...n_hd_6950.html" onclick="window.open(this.href);return false;
Modelli AMD Radeon 6970 disponibili in commercio:
VTX
Asus
Sapphire:
Sapphire gamer edition
XFX
His
Club 3d
Gigabyte
MSI
AMD Radeon 6950 modelli in commercio:
xfx
Vtx
Sapphire:
HIs
Club 3d
Gigabyte
Asus
Msi
Tool utili e Faq
No luser cut per gli stream processors sulla 6950, per abilitarli basta un flash del bios (per le versioni attualmente in commercio)
guida al flash:
crare una chiavetta bootabile scaricando hp format tool e il boot di windows xp
inserire all'interno della chiavetta ati flash e il bios desiderato, spegnere il pc e settare lo switch in posizione 1
accendere il pc bootando da chiavetta e premere i seguenti comandi:
atiflash -unlockrom 0
atiflash -f -p 0 nomebios.bin/rom
riavviare il pc
Variazione consumi moddando la 6950@6970:
Nel caso andasse qualcosa storto:
Nulla di piu' semplice, riportare lo switch in posizione 2
Accendere il pc preparandosi a flashare il bios con uno non corrotto
prima di effettuare il flash spostare lo switch in posizione 1, riavviare il pc
Real time demo
http://developer.amd.com/samples/demos/ ... Demos.aspx
Cat 10.12 RC3 December 16, 2010 HotFix
http://support.amd.com/us/kbarticles/Pa ... otfix.aspx
Cat 10.12 68.79.6RC5.
http://download.gigabyte.eu/FileList/Dr ... 9.6rc5.exe
Sapphire Trixx 0.3.2:
http://www.mediafire.com/?rygfi6fooc8kccz
Bios 6970 sapphire:
http://www.mediafire.com/?xebhto7bc2izkdr
Bios 6970 Asus
http://www.mediafire.com/?4sopq35l8oexace
Ati Flash
http://www.mediafire.com/?935x5q4yup8logo
hp format tool:
http://files.extremeoverclocking.com/file.php?f=197
Ati tray tool
download
